Brockhaus Heuer Bench Vice 101V, 120 - 160 mm

• Special version: completely galvanized!
• Zinc spindle key with riveted safety rings made of steel
• Drop-forged front jaw
• Protected precision spindle bearing
• with replaceable, turnable jaws
• Slim but stable guide tracks (drop-forged) provide greater clamping depth
• High and optimally distributed clamping force due to centrally arranged and electro-galvanised spindle with double-action, rolled trapezoidal thread for high strength and corrosion protection
• Hardened pipe-gripping jaws as production standard
• Drop-forged rear jaw with specially-formed anvil (49x47 mm)
• Strong, forged spindle nut
• Drop-forged guide plates
• Guide adjustable by centrally located screw
• Internal dual-prism guide track preventing fouling and damages. Large track surfaces fully machined to guarantee precision and long service life
• Made in Germany

Technical details

No	Jaw width mm	Span width mm	Span depth mm	Pipe gripping jaw Ø mm	Maintenance kit No	Weight netto kg	EAN 4010898
101123	120	0.0 - 150.0	65.0	16.0 - 55.0	197050	9.000	+000309
101143	140	0.0 - 200.0	80.0	27.0 - 70.0	197050	16.000	+000316
101163	160	0.0 - 225.0	100.0	27.0 - 100.0	197050	27.000	+000323
