KUKKO 20-SP 2-arm Universal Puller, 11 - 350 mm

• Narrow puller jaws grip optimally in tight and hard-to-reach areas
• Screw connection allows easy loosening and particularly tight fastening of the jaws with an Allen key
• Application also for eccentric components through freely movable, sliding puller jaws on the crossbar
• Hexagonal profile on the crossbar for secure counterholding
• Quick-adjustable trigger hooks guarantee instant adjustment to any span between 11-120 to 21 - 350 mm
• Abschersichere Aufhängung der Klaue im Gleitstück (Armlock Technology)
• Safety hook suspension of the claw in the sliding piece (Armlock Technology)
• Secure mounting of the spindle through the rotating spindle tip both on smooth surfaces and during centering (Switch Technology)
• By combining the hooks, a maximum reach of xxx mm can be achieved
• Optional convertible from an External Puller to an Internal Extractor by flipping the Jaws
• Anti-slip safety at the spindle neck for safe working with socket wrenches
• Almost all components available as replacement parts, time-saving order process thanks to numbering system
• For the safe extraction of bearings, gears and pulleys
• 2 or 3 pairs of jaws in various lengths
• Material: Tool Steel
• Made in Germany

Technical details

No	mm/inch	mm/inch	mm/inch	mm	t	Nm	EAN 4021176
20-10-SP	11 - 120 7/16 - 4 3/4	350 13 3/4	70 - 180 2 3/4 - 7 1/16	17.0	2.5	35	+461514
20-20-SP	26 - 200 1 1/32 - 7 7/8	300 11 13/16	100 - 260 3 15/16 - 10 1/4	22.0	5.0	120	+701856
20-30-SP	21 - 350 13/16 - 13 3/4	400 15 3/4	180 - 440 7 1/16 - 17 5/16	27.0	7.0	250	+701931
