Stahlwille 50184005 Torque Wrench 730/5 Quick, 6 - 50 Nm
USD 331,91 -15% RRP USD 390,49
add. 19 % VAT excl. shipping costs
weight 1.12 kg
Low stock, ships in 7 - 10 days. Additional items can be ordered Datum!!
Product.Nr. 50184005
0 Review(s)
product description
Stahlwille 50184005 Torque Wrench 730/5 Quick, 6 - 50 Nm
- click-type
- mount for interchangeable insert/shell tools
- Improved accessibility and operation of the locking lever concealed inside the handle
- Ergonomically designed, non-slip adjusters with a thumb recess – for rapid, safe adjustment of the scale to set the required torque
- The QuickRelease safety lock secures the insert tools while, at the same time, enabling them to be changed quickly and easily – inadvertent release is no longer a risk
- Optimised convex handle for strain-free working. Resistant to oils, grease, fuels, brake fluids and Skydrol
- The new design, with opposing V-shaped sights facilitates fast, accurate setting even at an awkward reading angle. With a Vernier scale in Nm/ft lb or Nm/in lb
- In contrast to conventional torque wrenches, it is not necessary to reset the wrench to zero after each job to unload the spring
- can be applied for either clockwise or anticlockwise tightening by turning the inserts over
- any force applied to the tool after the 'click' or applied in the opposite direction to the current function - e.g. forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it
- Protect all sensitive parts through the robust steel tube housing
- calibration using perfectControl calibrating unit No 7794 or calibration system No 7706. Adjustment without disassembly
- display deviation value ± 4 %
- with certificate
- Delivery without insert tools (please order separate)
- Made in Germany
- Delivery in sturdy Hexa-pack
Technical details
![]() |
50184005 |
Article No | 730/5 Quick |
![]() |
9 x 12 |
l mm | 315.0 |
Torque min./max. Nm/ft lb | 6 - 50/5 - 36 |
Scale division Nm/ft lb | 2/1 |
b mm | 28.0 |
h mm | 23.0 |
LF mm | 288.0 |
SF mm | 17.5 |
EAN | 4018754268856 |
Please note: The image shows a representation only and is provided by Stahlwille
