Stahlwille 50184005 Torque Wrench 730/5 Quick, 6 - 50 Nm

• click-type
• mount for interchangeable insert/shell tools

• Improved accessibility and operation of the locking lever concealed inside the handle

• Ergonomically designed, non-slip adjusters with a thumb recess – for rapid, safe adjustment of the scale to set the required torque

• The QuickRelease safety lock secures the insert tools while, at the same time, enabling them to be changed quickly and easily – inadvertent release is no longer a risk

• Optimised convex handle for strain-free working. Resistant to oils, grease, fuels, brake fluids and Skydrol

• The new design, with opposing V-shaped sights facilitates fast, accurate setting even at an awkward reading angle. With a Vernier scale in Nm/ft lb or Nm/in lb

• In contrast to conventional torque wrenches, it is not necessary to reset the wrench to zero after each job to unload the spring


• can be applied for either clockwise or anticlockwise tightening by turning the inserts over
• any force applied to the tool after the 'click' or applied in the opposite direction to the current function - e.g. forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it
• Protect all sensitive parts through the robust steel tube housing
• calibration using perfectControl calibrating unit No 7794 or calibration system No 7706. Adjustment without disassembly
• display deviation value ± 4 %
• with certificate
• Delivery without insert tools (please order separate)
• Made in Germany
• Delivery in sturdy Hexa-pack

Technical details

No	50184005
Article No	730/5 Quick
mm	9 x 12
l mm	315.0
Torque min./max. Nm/ft lb	6 - 50/5 - 36
Scale division Nm/ft lb	2/1
b mm	28.0
h mm	23.0
LF mm	288.0
SF mm	17.5
EAN	4018754268856
